Plastic Medicine Bottle Plastic Water Bottle Making Machine 50ml 100ml TRITAN

Guangzhou JASU Precision Machinery Co., LTD

Plastic Medicine Bottle Plastic Water Bottle Making Machine 50ml 100ml TRITAN

  • 1
  • 2

Brand Name : JASU

Model Number : ISB 1100AN-3

Certification : CE, ISO, BV, SGS, UKAS, LAF

Place of Origin : Guangzhou, China Mainland

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T

Supply Ability : 500 Sets Per Month

Delivery Time : 34-50 Days

Packaging Details : Wooden Case

Products Name : Bottle Making Machine For Sale, Plastic Blowing Machine Price, Bottle Blowing Machine

Use : PET Bottle Automatic Production, PET Bottle Manufacturing

Automation : Full Automatic

Serve For : Empty Plastic Bottles, Empty PET Bottles, Empty Spray Bottles, Empty Cosmetic Bottles

Applicable Resins : PET, PETG, PC, PCTG, TRITAN, PMMA, and Many Other Thermoplastics

Machine Type : Packaging Machines, Plastic Machines, Blowing Machines

Cavity : Multi-cavity, 10 Cavity or More

Dimension (L*W*H) : 4.2*1.75*3.4 m

Contact Now

Bottle Making Machine for Sale, Plastic Blowing Machine Price, Bottle Blowing Machine
Why bottle making machine for sale / plastic blowing machine / bottle blowing machine

Without the need to outsource preforms or for additional capital investment in injection machinery purchase, the single-stage process provides advantages of lower operational cost and occupies less floor space (No need for preform storage).

Automatic production, no need to remove burrs, no need to transport preform, greatly save raw material and labor costs.

Superior container clarity and gloss, as there is no preform surface deterioration due to storage and transport.

Suitable for all containers irrespective of neck design and weight, considering that there is no restriction to only the preforms available on the market.

The one step method allows more flexibility of shapes and geometries when processing because the preform is stretch blown immediately into the blow cavities which gives greater control of wall thicknesses.

Shaping ability: the preform remains warm during the process, which could present a better shaping ability, a sharper angle.


Datum of Injection Stretch Blow Molding Machine / bottle making machine / plastic blowing machine

Item Unit Machine Type
ISB 800AN-3
Injection Part Screw Diameter mm 50
Screw L/D Ratio L/D 20.5:1
Screw Speed r/min 0-150
Theoretical Injection Capacity cm3 481
Injection Pressure MPa 176
Max. Hydraulic Pressure Kg/cm 140
The Actual Injection Quantity g(ps) 452
Oz 16
Screw Stroke mm 245
Clamping Part Blow Clamping Force KN 80
Clamp Tonnage KN 400
Wheel Diameter mm 800
Max. Height PP, PET, PETG, Tritan, PS, PC mm 200
PC, PETG, Tritan, PS mm 220
Open Vertical Mode Trip mm 570
Others Max. Pump Pressure MPa 16
Servo Motor Kw 22
Mode Opening/Locking Motor (Double Pump) Kw 22
Electric Power Kw 12.2
Tank Volume L 420
Dimension of Machine m 4.2*1.75*3.4
Machine Weight T 6
--Parameters are subject to change without prior notice.
--Providing PC, PET, PP, PS, PETG, TRITAN screw barrels according to customers' requirements.

Plastic Medicine Bottle Plastic Water Bottle Making Machine 50ml 100ml TRITAN


Bottle blowing machine is widely used for various plastic materials and has broad application prospects

Injection blowing molding is suitable for PET, High transparent PP, PCTG, PETG, SAN, PC, PMMA, PS, Tritan (BPA Free).

Cosmetic bottles: mascara bottles, lotion bottles, cream bottles etc

Pharmaceuticals bottles / Medicine bottles: syrup bottles, eye drops bottles, pills bottles, oral liquid bottles, intravenous drip bottles etc.

Daily use bottles, households bottles, detergent bottles, laundary bottles, disinfectant bottle, personal care bottles

Food and beverage bottles, food and dairy bottles, carbonated drink bottles, oil bottles, dressing bottles, condiment bottles

Baby Feeding bottles

Pesticide bottle

Plastic Medicine Bottle Plastic Water Bottle Making Machine 50ml 100ml TRITAN


Why JASU Precision Machinery?


We are THE FIRST to manufacture One Stage Injection Stretch Blow Molding Machine in China on basis of digestion and absorption of the advanced technology from Japan and Germany.
Manufacturer/Direct Factory with production base takes 24000m2.
Own highly qualified technical staffs (20-30 persons) and R/D center.
Obtained a number of technical patents.
Market network throughout the country , and export to many countries of East Europe, South America, South Africa etc.
Our machine enjoyed high reputation among customers.
Overseas sales increase 33% annually.
Service technicians (holding visa and passport) are on call and able to serve on site and instruct via voice and videos.

Plastic Medicine Bottle Plastic Water Bottle Making Machine 50ml 100ml TRITAN


Question & Answer


Q1: Are you a factory or trading company?
A1: We are established in 2003, a actual factory and manufacturer in the line of injection blow molding machine for 18 years.
Q2: Where is your factory located? How can I visit you?
A2: Our factory is located in Panyu District, Guangzhou, Guangdong Province, China, about 48 minutes by high-speed railway from Hong Kong.
5 minutes driving away from Shiqiao subway station.
We can book hotel for you and pick you up from CAN BAIYUN airport or Guangzhou south railway station.
Q3: How about the payment term?
A3: Advancement (subject to our marketing strategy and both parties' discussion) and settle the balance payment prior to delivery.
Q4: What about your main market?
A4: Our machines were sold well in China, also exported and enjoyed a good reputation among customers from Europe, Russia, Southeast Asia, Middle and South America, Africa etc.
Our customers widely spread over Russia, Italy, Poland, Turkey, Netherlands, Sweden, Bulgaria, Brazil, Ecuador, Thailand, India, Myanmar, Malaysia, Vietnam, Cambodia, Egypt, Algeria, South Africa, Ivory Coast, Philippines, Bangladesh......
Q5: How does your factory do regarding quality?
A5: Quality is the most important principle. JASU people always attach great importance to quality controlling from the very beginning to the very end. Our factory has passed ISO and CE certification. Patents and many other certificates obtained also tells this.
Q6: What about warranty and do the engineers available to overseas?
A6: One year warranty. During this period, if you need any support on installation, adjustment , operation or maintenance, our engineers can go abroad to fix for you.
Q7: Others?
A7: We will request the working voltage and power frequency at the buyer's side when he placing the order.
Each order will be fulfilled as a turn key project of machine.

  1. We will check and test the machine and send the video to the customer for reference prior the delivery.
  2. Attache/send an operational manual in English version with the shipment.
  3. To use the machine only need to connect power and connect to the air supply and water supply according to the manual or video instructions if requested.
  4. Service technicians are on call to instruct via voice and videos. They all hold visa and passport and be able to serve on site.

Plastic Medicine Bottle Plastic Water Bottle Making Machine 50ml 100ml TRITAN
